D400 Electrical Power Transient Voltage Spike Lightning Strike Surge
Protection Suppression EMI/RFI EMI RFI filtering protects
sensitive industrial, commercial, and medical equipment Modular design allows protection replacement, if needed, without dismounting the panel Compact size enables close mounting to the protected panel to minimize wire length and maximize performance 400,000 Amp peak surge current capacity ensures long service life |
|
|
|
DITEK’s D400 industrial surge protectors are designed to provide maximum system protection, even in the most severe environments. High peak surge current allows the D400 to divert more, and more extreme, transient surges than smaller units. Modular design allows surge protection replacement, if needed, without removing the surge protector. Available in a wide range of voltage configurations and offering a variety of options, the D400 is an excellent choice for electrical panel protection. |
|
D400 400kA Modular Industrial Surge Protection |
|
|
APPLICATION FEATURES: Suitable for use on service entrance, distribution, and branch panels EMI/RFI EMI RFI filtering protects sensitive industrial, commercial, and medical equipment Modular design allows protection replacement, if needed, without dismounting the panel Compact size enables close mounting to the protected panel to minimize wire length and maximize performance
|
APPLICATION FEATURES: 400,000 Amp peak surge current capacity ensures long service life Available in 7 voltage configurations Diagnostic LEDs, one per phase, audible alarm with enable/disable switch, and surge counter indicate system power and TVSS function. Dry Relay Contacts allow remote notification of TVSS status/power loss
|
|
PRODUCT SPECIFICATIONS: Features Agency Approvals : UL 1449, 2ndEd. 2007, cUL, UL1283, CSA C22.2 No. 8-M1986 (E.F.N. No. 516)IEEE Location Category: Category A, B and C Suppressor Type: Parallel configuration, external mount, modular SPD Peak Surge Current: 400,000A/Phase, 200,000A/Mode Short Circuit Current Rating: 200,000A
|
PRODUCT SPECIFICATIONS: Protection Modes: All Modes –L-G, L-N, L-L, N-G (Single Phase and Wyeconfigurations), L-L (Delta) EMI/RFI Filtering: -30dB Response Time: <1ns Operating Frequency: 50Hz –60Hz Temperature Range: -40°–150°F (-40°–65°C) Weight: 38.7lb. (17.6kg) With Disconnect: 50.6lb. (23kg) Housing: NEMA 3R/12 Steel Warranty: Ten Year Limited WarrantyIndustrial
|
D400 400kA/Φ, 200kA/Mode Industrial Surge Protection
WEB PRICING
| MODEL# | DESCRIPTION | WEB PRICE EACH |
| D400-120/2401
|
120/240 Vac 1-Phase Wye,
3 Wire (+G)
|
|
| D400-120/2083Y
|
120/208 Vac 3-Phase Wye,
4 Wire (+G)
|
|
| D400-220/3803Y
|
220/380 Vac 3-Phase Wye,
4 Wire (+G)
|
|
| D400-120/240HL
|
240/120 Vac Split-Phase
Delta
|
|
| D400-2403D
|
240 Vac 3-Phase Delta,
3 Wire (+G)
|
|
| D400-277/4803Y
|
277/480 Vac 3-Phase Wye,
4 Wire (+G)
|
|
| D400-4803D
|
480 Vac 3-Phase Delta,
3 Wire (+G)
|
|
| D400-347/6003Y
|
347/600 Vac 3-Phase Wye,
4 Wire (+G)
|
|
| D400-6003D
|
600 Vac 3-Phase Delta,
3 Wire (+G)
|
|
| D OPTION
|
Integral Disconnect
|
$875.00
|
| DTK-RMU
|
Remote Monitor
|
$345.00
|
|
