PALADIN TOOLS LC CST STRIPPERS |
||||||
|
The newest line of coaxial cable strippers combines high-performance and ergonomic design at an affordable price. Easily remove the outer jacket, shield braid and inner dielectric in a single step.
|
| ORDERING | PART NO. | PRESENT STRIP LENGTHS* | STRIP TYPES | CABLE USAGE |
| LC CST-58/59 | 1255 | 0.315" outer jacket, 0.157" inner dielectric | 2- & 3-level, adjustable | RG58, RG59, RG62 AU & RG6 LMR 195, LMR 300, LMR 400 |
| LC CST-11 | 1256 | 0.315" outer jacket, 0.157" inner dielectric | 2- & 3-level, adjustable | RG8, RG11 & RG213, LMR 300, LMR 400 |
| LC CST CATV "F" | 1257 | 0.236" outer jacket | 2-level | RG59, RG6 & RG6 QUAD CATV "F" (preset for RG6 CATV "F") |
| LC CST-Mini | 1258 | 0.344" outer jacket, 0.094" inner dielectric | 2- & 3-level, adjustable | RG178, RG179, RG188, AT&T 735(A), NT735, Belden 1855A, Belden 8218, LMR 100A, RG180, RG187, RG188A, RG405 and more |
| LC CST SealTite™ | 1259 | 0.472" outer jacket | 2-level | RG59/6/60S (preset for RG60S SealTite™ connectors) |
| Replacement Blade | 2263 | -- | -- | -- |
| *To adjust strip lengths simply change blade locations in the lower jaw to attain the following: .157" (4 mm), .236" (6 mm), .315" (8 mm), .394" (10 mm) and .472" (12mm) |
| PALADIN TOOLS LC CST STRIPPERS PRICING CHART | ||
| Part Number | 3+ | 1+ |
| 1255 | 16.99 | 17.84 |
| 1256 | 16.99 | 17.84 |
| 1257 | 16.99 | 17.84 |
| 1258 | 16.99 | 17.84 |
| 1259 | 16.99 | 17.84 |
| 2263 | 8.65 | 9.08 |
CALL US TOLL FREE: 1-800-843-6036
Prices Subject to Change Without Notice.
Product Design and Specifications Subject to Change Without Notice.
