PALADIN TOOLS 1300 SERIES CRIMPERS

The original interchangeable-die crimping system..all the rest are mere copies of our innovation.


Paladin's 1300 Series is the original interchangeable-die crimping system -- all the rest are mere copies of their innovation.  It continues to be the answer for precision-crimping at an affordable price with over 45 die sets available for the most popular connectors.  See crimp chat below for specific connector and crimp dimensions.

FEATURES:

  • Fully-ratcheting cycle with built-in safety release
  • Interchangeable die sets of heat-treated steel for long life
  • Easy to use and maintain
  • Available as complete tool with die set inserted or separate tool frame and individual die sets
  • Foam-lined case available to hold frame and 6 die sets together
  • Five year warranty

ADVANTAGES:

  • EZI-Change™ die screws make changing dies quick and easy -- no screwdriver required
  • Most precise and tightest tolerances on die sets in the industry
  • Six ratchet gear settings for optimum crimp performance
TECHNICAL WEIGHT LENGTH
Crimp tool frame

10.4 oz (296 g)

8.9" (225 mm)
Die Set

2 oz. (57 g)



ORDERING PART NUMBER
Crimp tool frame

1302
Replacement EZI-Change™ die screws (2) 2303
Replacement fixed die screws (2) 2306
Replacement handles 1300.9
1300 crimp case 901013



Part Numbers Connector Type(s) Cable Type(s) Crimp Sizes/Type(s) Connector Manuf./Remarks
Tool & Die: 1317

Die Only:  2034

 BNC/TNC, 3 Piece RG58, RG59, RG62AU 0.256"/02.13"/0.068" HEX Common 2-piece and 3-piece BNC/TNC
Tool & Die: 1319

Die Only: 2039

 N-type, MS39012 Type RG8, RG11, RG214, RG216 0.415"/0.095" HEX Crimps Pins and Ferrules
Tool & Die:  1328

Die Only: 2042

 CATV "F" Type RG59, RG6 Video Cable 0.346"/0.319"/0.256" HEX CATV "F" 1- and 2 - piece
Tool & Die:  1335

Die Only: 2046

 Thinnet, BNC/TNC, Mini-UHF 50 and 75 ohm RG58, RG174, AT & T 735 & Belden 1855A 0.213"/0.178"/0.068" HEX and 0.042"SQ 50/75 ohm small 2-piece and 3-piece BNC/TNC (Kings, ADC, etc.)
Tool & Die:  1336

Die Only: 2047

 BNC/TNC, and Mini-UHF 50 and 75 ohm RG59, RG62, Belden 8281 & 1505A 0.315"/0.252"/0.068" HEX and 0.042"SQ 75 ohm 2-piece and 3-piece BNC/TNC (Kings, ADC, Amphenol, etc.)
Tool & Die: 1337

Die Only: 2050

 BNC/TNC RG8, RG213 0.402"/0.094"/0.079" HEX Common 2-piece and 3-piece BNC/TNC/SMA/SMB
Tool & Die: 1338

Die Only:

2051

 BNC/TNC RG174, RG179, & Small Cable Conn. 0.178"x0.128"/0.068" HEX Common 2-piece and 3-piece BNC/TNC/SMA/SMB
Tool & Die: 1347

Die Only: 2075

 BNC/TNC RG58, RG59, RG62AU, RG6 Teflon/Plenum 0.325"/0.215"/0.065" HEX 2-piece and 3-piece BNC/TNC (AIM/Cambridge, GEM)
Tool & Die: 1348

Die Only: 2076

 BNC/TNC RG6, RG58 0.320"/0.210"/0.185" HEX 2-piece BNC/TNC(AIM/Cambridge, Kings, Amphenol, GEM)
Tool & Die: 1349

Die Only: 2082

 BNC/TNC Belden 1694A, & 1695A 0.315"/0.068" HEX Common 2-piece and 3-piece BNC/TNC
Tool & Die: 1356

Die Only: 2045

 BNC and CATV "F" Type & HDTV RG6 and RG6 Quad, Belden 1694A 0.360"/0.324"/0.068 HEX Common 2-piece and 3-piece BNC/TNC, & CATV "F" 1-and 2-piece
Tool & Die:  1363

Die Only: 2653

 SMA, SMB, Mini-59 BNC/TNC, Mini-UHF RG58, Mini-59, RG-174, small coax & Belden 1855A 0.128"/0.213"/0.197"/0.178"/0.068" HEX and 0.042" SQ Common 2-piece and 3-piece SMA/SMB/BNC/TNC & mini-UHF
Tool & Die: 1365

Die Only: 2656

 N-type plugs RG8, RG11, RG213 0.429"/0.100"/0.080" HEX Common 2-piece and 3-piece N-Type (Kings, ADC, Amphenol, etc.)
Tool & Die:  1366

Die Only: 2648

 HDTV SMA, True 75-ohm BNC/ TNC, Mini-UHF, 75 ohm RG174, RG59/62, mini-coaxial & Belden 1855A 0.255"/0.197"/0.178"/0.068" HEX and 0.042"SQ Common 2-piece and 3-piece BNC/TNC (Kings, ADC, Amphenol, etc.)
Tool & Die: 1367

Die Only: 2649

 HDTV BNC/TNC/CATV "F" True 75-ohm RG59, RG6, Belden 8281, 1694A & 1505A 0.324"/0.255"/0.068" HEX and 0.052"/0.042" SQ Common 2-piece and 3-piece BNC/TNC (Kings, ADC, Amphenol, etc.)
Tool & Die: 1368

Die Only: 2657

 HDTV BNC/TNC True 75-ohm RG6, Belden 1694 & 1694A 0.278"/0.275"/0.068" HEX and 0.042" SQ Common 3-piece BNC/TNC (Kings & ADC HDTV)
Tool & Die: 1387

Die Only: 2687

 CATV "F" & RJ45 RG56 and RG6 Quad, Cat 5e, Cat6 0.360"/0.324" HEX Common 2-piece CATV "F" & WE/SS style RJ45

CALL US TOLL FREE:  1-800-843-6036

OnLine Order

More Professional Grade Tools

MORE PALADIN TOOLS

Email Us

midsouthcable.com Home Page



CRIMPERS - TWISTED PAIR CABLE - 1300 SERIES
PART NUMBERS DESCRIPTION CRIMP STYLE (28-22 AWG/.08-.34mm2) MANUFACTURERS
Tool & Die: 1307   Die Only:  2061 RJ45 - 8P8C (8 Pin) Flat/Round, Solid/Stranded/RJ45 Unkeyed WE and SS Western Electric (WE) Stewart Connector (SS)
Tool & Die: 1340   Die Only:  2062 RJ11 & RJ12 - 6P6C, 6P4c, 6P2C Flat/Round, Solid/Stranded/RJ11/RJ12 Unkeyed WE and SS Western Electric (WE) Stewart Connector (SS)
Tool & Die: 1341    Die Only: 2063 RJ22, Handset 4P4C (4 Pin) Flat/Round, Solid/Stranded/4 Pin Handset WE and SS Western Electric (WE) Stewart Connector (SS)
Tool & Die: 1342   Die Only: 2064 RJ45-8P8C (8 Pin) Flat/Round, Solid/Stranded RJ45 Unkeyed AMP AMP (Tyco) Inc. Connectors Only
Tool & Die: 1343   Die Only: 2065 RJ11 & RJ12 - 6P6C, 6P4C, 6P2C Flat/Round, Solid/Stranded/RJ11/RJ12 Unkeyed AMP AMP (Tyco) Inc. Connectors only
Tool & Die: 1344   Die Only: 2067 RJ11 DEC-MMJ OFFSET (6P6C) Flat/Round, Solid/Stranded/RJ11 DEC-MMJ OFFSET AMP (Tyco) Inc. Connectors Only
Tool & Die:  1345    Die Only: 2068 RJ50 - 10P10C (10 Pin) Flat/Round, Solid/Stranded/RJ50 Unkeyed WE and SS Virginia Plastics (VP)
Tool & Die: 1361   Die Only: 2032 British Telecom 6 Pole Plug Flat/Round, Solid/Stranded/BT 6 Pole British Telecom        Plugs Only
Tool & Die: 1370   Die Only:  2670 SHIELDED RJ45, Stewart Connector, Short Body Rounded, Shielded (STP), RJ45 STP Stewart Connector, Short Body Stewart Connector
Tool & Die: 1371   Die Only:  2671 SHIELDED RJ45, Hirose Connectors, Long Body Round, Shielded (STP) RJ45 STP Hirose Connectors, Long Body Hirose
Tool & Die: 1372   Die Only: 2672 SHIELDED RJ45, Hirose Connectors, Short Body Round, Shielded (STP), RJ45 STP Hirose Connectors, Short Body Hirose
Tool & Die: 1373    Die Only: 2673 SHIELDED RJ45, Molex Connectors 5.00mm Dia. Round, Shielded (STP), RJ45 STP Molex Connectors Molex
Tool & Die: 1374   Die Only: 2674 SHIELDED RJ45, AMP/Molex Connectors 6.0mm Dia. Round, Shielded (STP), RJ45 STP AMP & Molex AMP (Tyco) Inc. & Molex
Tool & Die: 1388   Die Only: 2688 RJ45 SNAGLESS - 8P8C (8 Pin) Flat/Round, Solid/Stranded, RJ45 Unkeyed WE/SS Wetern Electric (WE) Stewart Connector (SS) Hubbell Premise Wiring
Tool & Die: 1387   Die Only: 2687 RJ45 WE/SS & RG6/RG6 Quad CATV "F" UTP 4-Pair & RG6/RG6 Quad RJ45 WE/SS 8-pin & .360" (9.1mm) HEX/.324" (8.2mm) HEX For Standard RJ45 WE/SS Modular Plugs and 1-piece RG6/RG6 Quad CATV "F" conns.



PALADIN TOOLS COAXIAL CABLE CRIMPER PRICING CHART
Part Number 3+ 1+

1302

 34.79 36.53
2303 6.52 6.85
2306 1.80 1.89
1300.9 2.92 3.07
901013
1317 51.95 54.55
2034 22.96 24.11
1319 51.95 54.55
2039 22.96 24.11
1328 51.95 54.55
2042 22.96 24.11
1335 51.95 54.55
2046 22.96 24.11
1336 51.95 54.55
2047 22.96 24.11
1337 51.95 54.55
2050 22.96 24.11
1338 51.95 54.55
2051 22.96 24.11
1347 51.95 54.55
2075 22.96 24.11
1348 51.95 54.55
2076 22.96 24.11
1349 51.95 54.55
2082 22.96 24.11
1356 51.95 54.55
2045 22.96 24.11
1363 51.95 54.55
2653 22.96 24.11
1365 51.95 54.55
2656 22.96 24.11
1366 51.95 54.55
2648 22.96 24.11
1367 51.95 24.11
2649 22.96 24.11
1368 51.95 54.55
2657 22.96 24.11
1387 56.68 59.51
2687 29.98 31.48



CRIMPERS - TWISTED PAIR CABLE - 1300 SERIES
Part Number 3+ 1+
1307 51.95 54.55
1340 51.95 54.55
1341 51.95 54.55
1342 51.95 54.55
1343 51.95 54.55
1344 51.95 54.55
1345 51.95 54.55
1361 51.95 54.55
1370 51.95 54.55
1371 51.95 54.55
1372 51.95 54.55
1373 51.95 54.55
1374 51.95 54.55
1388
1387 56.68 59.51
2061 22.96 24.11
2062 22.96 24.11
2063 22.96 24.11
2064 22.96 24.11
2065 22.96 24.11
2067 22.96 24.11
2068 22.96 24.11
2032 22.96 24.11
2670 24.03 25.23
2671 24.03 25.23
2672 24.03 25.23
2673 24.03 25.23
2674 24.03 25.23
2688
2687 29.98 31.48

CALL US TOLL FREE:  1-800-843-6036

OnLine Order

More Professional Grade Tools

MORE PALADIN TOOLS

Email Us

midsouthcable.com Home Page

Prices Subject to Change Without Notice.

Product Design and Specifications Subject to Change Without Notice.
