"proSplice" UL Listed Splice Kits

• Direct burial splice enclosure kit
• No heat shrink tubing or epoxy needed
• Fast, clean, reusable
• A twist of the wrist and a water tight mechanical connection is completed
• Rated to 600V
• UL listed
• BellCore audited
• CSA
• Made in USA
• SKI - 14-10 AWG UF Cu/Sol/Str. includes 4 butt splices and grommets
• SKS - proSplice shells only
• SK1C - 14-10 AWG UF Cu/Sol/Str. includes classic SK830 Quad connector and grommets
• SK2 - 12-6 AWG USE Cu/Al includes connector and grommets
• SK3 - 6-1 AWG USE Cu/Al includes connector and grommets
• SK4 - 1/0 USE to 350 MCM includes grommets, connector not included
• PK1 - 2-6 pair buried phone wire, coaxial RG6 & RG59, includes grommets, connectors not included

"proSplice" Extenders

• Increases cavity size of all proSplice kits.  Allows for larger coax connectors and additional phone wires to be terminated.  Available in 4", 6", 8" and 10" lengths
• Extenders come with SKS shells.   Grommets not included
• Catalog #s are: EXT4, EXT6, EXT8, EXT10
• UL listed
• BellCore audited
• CSA
• Made in USA

Call Toll Free 1-800-843-6036

Place On-Line Order

Call Toll Free 1-800-843-6036

Place On-Line Order

SKUF

• Direct burial splice enclosure kit for #14/2 and #12/2 UF wire
• Includes grommets and 3-butt splice connectors
• Made in USA

"proSplice" Taps

• 3 or 4 wire taps with no tape or heat shrink needed
• T-splice with single in and double out
• Four wire splice with double in and double out
• Dead-end splice available
• UL listed
• BellCore audited
• CSA
• Made in USA

CALL FOR PRICING

SKCX

• Direct burial splice enclosure kit for coaxial RG6, RG11, RG59
• Dimensions:  6" long x 3/4" diameter
• Includes grommets
• UL listed
• Made in USA

SK830 UL Listed UF Splice Kit

• 14 to 8 gauge copper wire rated to 600V
• For direct underground burial of UF wire
• Includes 4 conductor splice connector
• Includes the UL listed shrink tubing required for application
• Unit is the FIRST UL listed Splice Kit for direct underground burial UF type wire

SK831 UL Listed Underground Splice Kit

• 8 to 2 gauge copper/aluminum wire rated to 600V
• For direct underground burial
• Includes single conductor mechanical connector
• Includes UL listed shrink tubing required for splice
• Unit First UL listed Splice Kit for direct burial for 8 to 2 gauge Cu/Al wire

SK832 UL Listed Underground Splice Kit

• 1 gauge to 250 MCM Cu/Al wire rated to 600V
• For direct underground burial
• Includes single conductor mechanical connector
• Includes UL listed shrink tubing required for splice
• Unit is First UL listed Splice Kit for direct burial to #1 to 250 MCM Cu/Al wire

Call Toll Free 1-800-843-6036

Place On-Line Order

Shrink Tube

ST Series Shrink Tube

• 4" sections

ST-48BP Series

• 4 ' sections blister carded

CALL FOR PRICING

BURIAL CABLE

[6]  89494-06  /  22/4 PR. UTP DIRECT BURIAL

[7]  89496-06  /  22/6 PR UTP DIRECT BURIAL

 [8]  89412-06  /  22/12 PR UTP DIRECT BURIAL

[9]  89425-06  /  22/25 PR UTP DIRECT BURIAL

[10]  89450-06  /  22/50 PR UTP DIRECT BURIAL

 [11]  894100-06 22/100 PR UTP  DIRECT BURIAL

Replacement Grommets

• Varying sizes for multiple applications
• For use with proSplice shells and extenders
• Sizes available for: RG6, RG11, RG59 coax wire, 2-4 pair telephone wire, #14/2, #12/2 UF wire, #12-#10 AWG wire, #8-#2 AWG wire
• Made in USA

Street Lighting Grommets

• Varying sizes for multiple applications
• Made in USA

CALL FOR PRICING
