D160 incorporates noise filtration and individually fused components for maximum performance and protection EMI/RFI filtering protects sensitive industrial, commercial, and medical equipment
Modular Electrical Surge Protection Suppressors with noise filter filtration as well as individually fused components for use in service entrance and branch panels
 1-800-843-6036 |
 |
OnLine Order
Supported Browsers IE, SAFARI, CHROME |
 |
 |
Separate modules per phase allow protection replacement, if needed, without dismounting the panel
|
DITEK’s D160 industrial surge protectors are designed to provide robust electrical system protection in the most demanding environments. The D160 incorporates noise filtration and individually fused components for maximum performance and protection. Available in a wide range of voltage configurations and offering a variety of options, the D160 is an excellent choice for electrical panel protection. Separate modules per phase allow protection replacement, if needed, without dismounting the panel |
Power Service Entrance Electrical Branch Panel Voltage Spike Lightning Suppressors with Noise Filtration Modular Surge Protection - 160,000 Amps/Phase, Modular, SCCR: 200kA
|
|
WEB PRICING BOTTOM OF PAGE
|
DITEK’s D160 industrial surge protectors |
|
| PRODUCT
FEATURES: Suitable for use on service entrance, distribution, and branch panels EMI/RFI filtering protects sensitive industrial, commercial, and medical equipment Separate modules per phase allow protection replacement, if needed, without dismounting the panel Compact size enables close mounting to the protected panel to minimize wire length and maximize performance 160,000 Amp peak surge current capacity ensures long service life
|
PRODUCT
FEATURES: Available in 8 voltage configurations Diagnostic LEDs(one per phase), audible alarm with enable/disable switch, and surge counter indicate system power and SPD function. Standard Dry Relay Contacts allow remote notification of TVSS status/power loss
|
|
Specifications
Agency Approvals: UL 1449, 2ndEd. 2007, cUL, UL1283, CSA C22.2 No. 8-M1986 (E.F.N. No. 516) IEEE Location Category: Category A, B and C Suppressor Type: Parallel configuration, external mount, modular SPD Peak Surge Current: 160,000A/Phase, 80,000A/Mode Housing: NEMA 3R/12 Steel Warranty: Ten Year Limited Warranty
|
Specifications
Short Circuit Current Rating : 200,000AConnection: #12 –#2 AWG terminals Protection Modes: All Modes –L-G, L-N, L-L, N-G (Single Phase and Wyeconfigurations), L-L (Delta) EMI/RFI Filtering: -30dBResponse Time: <1ns Operating Frequency: 50Hz –60Hz Temperature Range: -40°–150°F (-40°–65°C) Weight: 19.2 lb. (8.7kg) Wye44.5 lb. (20.2kg) Wye w/Disconnect28.5 lb. (12.9kg) Delta31.6 lb. (14.3kg) Delta w/Disconnect
|
Power - Service Entrance / Branch Panel Suppressors - 160,000 Amps/Phase, Modular, SCCR: 200kA
WEB PRICING
| MODEL# | DESCRIPTION | WEB PRICE EACH |
| D160-120/2401 | 120/240 Vac 1-Phase Wye, 3 Wire (+G) | $3,207.00 |
| D160-120/2083Y | 120/208 Vac 3-Phase Wye, 4 Wire (+G) | $3,207.00 |
| D160-220/3803Y | 220/380 Vac 3-Phase Wye, 4 Wire (+G) | $3,207.00 |
| D160-2403D | 240 Vac 3-Phase Delta, 3 Wire (+G) | $3,207.00 |
| D160-120/240HL | 240/120 Vac Split-Phase Delta | $3,207.00 |
| D160-277/4803Y | 277/480 Vac 3-Phase Wye, 4 Wire (+G) | $3,207.00 |
| D160-347/6003Y | 347/600 Vac 3-Phase Wye, 4 Wire (+G) | $3,207.00 |
| D160-4803D | 480 Vac 3-Phase Delta, 3 Wire (+G) | $3,207.00 |
| D160-6003D | 600 Vac 3-Phase Delta, 3 Wire (+G) | $3,207.00 |
| D OPTION
|
Integral
Disconect
|
$875.00
|
| DTK-RMU
|
Remote Monitor
|
$345.00
|
| DTK-160MFK
|
Flushmount Kit
|
$173.00
|
| DTK-SS
|
NEMA 4x Housing
- Wye configuration only
|
$722.00
|
|
