Universal Telephone Alerts (w/Strobe)

Telestrobes (Single Analog Phone Line and Low Voltage)

Telephone Alerts (Chime and Warble)

CA Common Audible Control Unit

Series TB - Telbells

Telephone Relays (Weatherproof AC/DC and Explosion Proof AC/DC)

Series UTA - Universal Telephone Alerts

Available features and options:  Color:  Gray   Four selectable sound patterns:  Horn, Bell, Vibrating Chime, Single Chime.  High output 109 dB piezo speaker.  Tamper resistant volume control.  Dip switch selectable.  Low current draw and REN.  Approvals:  UL Standard 1950.  Multiple voltage activation.

Model Number

Order Code

Description

Web Price

UTA-1

WL-6338

$125.04   $112.54

UTA-WH-VPS

WL-6348

$202.82   $182.54

Tone, Volume Range and Description

Horn

82-109 dB

Broadband Horn

Bell

76-104 dB

1560 Hz Modulated (0.07 Sec. ON/Repeat

Vibrating Chime

68-94 dB

700 Hz (1.0 Sec. Delay/Repeat)

Single Chime

68-94 dB

700 Hz (1.0 Sec. Delay)

dB @3 Feet (1 meter)

Model Number

Tones

48 VDC

24 VDC

24 VAC

90 VRMS/20 Hz

UTA-1

Horn

107

108

105

104

UTA-1

Bell

100

100

102

100

UTA-1

Vibrating Chime

94

96

99

97

UTA-1

Single Chime

94

96

100

96

UTA-WH-VPS

Horn

109

109

109

109

UTA-WH-VPS

Bell

104

104

104

104

UTA-WH-VPS

Vibrating Chime

94

94

94

94

UTA-WH-VPS

Single Chime

94

94

94

94

                                                                                                           Ring Voltage/Current Draw mA                                                      REN

Model Number

Tones

48 VDC

24 VDC

24 VAC

90 VRMS/20 Hz

UTA-1

Horn

26

30

46

1.6

UTA-1

Bell

10

9

39

1.4

UTA-1

Vibrating Chime

7

6

29

1.25

UTA-1

Single Chime

6

6

34

1.25

UTA-WH-VPS

Horn

3

2.5

4

.6

UTA-WH-VPS

Bell

3

2.5

4

.6

UTA-WH-VPS

Vibrating Chime

3

2.5

4

.6

UTA-WH-VPS

Single Chime

3

2.5

4

.6

                                          Voltage Range                          36-60                                 20-30                               20--30                                40-130

SERIES PS TELESTROBES

PS Telestrobes emit a high intensity flashing light when the telephone rings.  Designed for alerting the hearing impaired, for use in high-ambient noise environments, quiet hospital zones, libraries and broadcast studios.

Available features and options:  Single line phones.  RJ-11C modular plug-in connection.  Long life, low power consumption,  Easily mounts to interior surfaces.  Approvals:  ULS Standard 1459.

Model Number

Color

Order Code

Input Voltage

REN

Peak Candlepower

Web Price

 PS-11A-WPA

Gray/Single Analog Phone Line

WL-3858

40-130V,16-68 Hz, 115VAC

3

70,000

$101.69   $91.52

PS-115A-WPW

Gray/Single Analog Phone Line

WL-3413

50-130V, 20-30 hZ

1.5

8,000

$76.68   $69.01

PS-33A-WPA

Gray/Low Voltage

WL-3209

18-30 VAC or VDC

N/A

25,000

$88.90   $80.01

SERIES CH CHIMES AND SERIES WR WARBLE TELEPHONE ALERTS

High quality, compact signaling devices.  Easily connects to phone systems.  Enables any moderately noisy environments to have a loud telephone alert.

Available features and options:  Color:  Gray  Connects with standard RJ-11C Phone jack.  Adjustable tone and volume.  Indoor use, surface mountable.  Analog, AC and DC models.  UL 1459 Listed, FCC part 68 approved and DOC certified.

**CH-AT1-W, WR-AT1-W and CH-BT1 can be used on the Public Telephone Network or behind PBX with interrupted ring voltages from 40-130 V, 20-30 Hz.

SERIES CH-BT

Model Number

Order Code

Nominal Input Current or Voltage

Input Current or Voltage Range

dBA@ 1 meter

REN

Web Price

Chime up to 1000 sq. ft.

CH-AT1-W

WL-3198

     90 VRMS, 20-30 Hz

50-130 VRMS, 20-30 Hz

80

0.4

$75.02   $67.52

CH-AT2-W

WL-3199

0.02

18-30 VAC or VDC

80

N/A

$69.47   $62.52

Chime 1000-5000 sq. ft.

CH-BT1

WL-3823

90 VRMS, 20-30 Hz

40-130 VRMS, 20-30 Hz

90

0.4

$113.62   $102.26

CH-BT2

WL-4077

0.02 Amps

18-30 VAC or VDC

90

N/A

$113.62   $102.26

CH-BT4

WL-4078

0.01 Amps

38-60 VDC

90

N/A

$113.62   $102.26

Warble 1000-5000 sq. ft.

WR-AT1-W

WL-3862

90 VRMS, 20-30 Hz

50-130 VRMS, 20-30 Hz

90

0.8

$55.57   $50.01

SERIES CA COMMON AUDIBLE CONTROL UNIT

CA Common Audible Control Units monitor multiple analog telephone lines (tip and ring) to provide all call signaling, zoned signaling or night bell connection.  These control units also enable connection for operation of external audible or visual alerts to be operated directly off the telephone ring voltage output.

Available features and options:  (Common Audible)  UL Listed.  Enables key systems to have a dry contact closure to trigger other devices.  Easy connection to Wheelock dry contact interface.  Choice of two outputs for alert signal connections:  standard ringing voltage or contact closure.

Model Number

Color

Order Code

Application

Web Price

CA-312-1

Black

WL-3780

$108.36   $97.52

CA-622-1

Black

WL-3779

$169.49   $152.54

Input Voltage

Output

REN

55-130, V, 20-30 Hz

Ringing Voltage or Dry Contact Closure

1

SERIES TB - TELBELLS

TB-592 for phone systems with a programmed contact closure, DCI-24-24 power supply required.  TB-593:   REN: 1.6  For installation in Canada, a 7 ft. modular line cord w/CA-11 connector is required.

Model Number

Color

Order Code

Input Voltage

Input Current

dBA @ 10 ft.

Web Price

TB-591

Gray

WL-4102

38-60 VDC

0.025

100

$96.24   $86.62

TB-592

Gray

WL-4101

18-30 VAC/DC

0.025/0.030

100

$96.24  $86.62

TB-593

Gray

WL-4103

55-130 V, 20-30 Hz

N/A

95

$96.24   $86.62

TELEPHONE RELAY

Explosion Proof AC/DC

Available features and options:  Indoor, outdoor.  Explosion proof (XRT-T-40).  UL Listed, FCC registered.  Accepts RJ-11 phone plug.  AC/DC Relay.

Series CRT-T-40

Weatherproof AC/DC

Model Number

Order Code

Web Price

Weatherproof AC/DC

CRT-T-40

WL-0049

$158.37   $142.53

Explosion Proof Ac/DC

XRT-T-40

WL-0221

$364.79   $328.31

Input Voltage

AC Contact Ratings/115 volt

AC Contact Ratings/230 volts

DC Contact Ratings/115 volts

REN

CRT-T-40/ 39-150 V, 20-30 Hz

5 Amps

2 Amps

500mA

0.6

XRT-T-40/39-150 V, 20-30 Hz

5 Amps

2 Amps

500mA

0.6
