SMOKE DETECTOR DAMAGE STOPPER«

Clear, flush mount Damage Stopper with mounting hardware.There's no longer any reason to risk malfunction of  your critically important smoke detectors from accidental or intentional damage.  This Stopper is easy to install in areas where severe vandalism or physical abuse is causing false fire alarms or high maintenance costs to your smoke detectors.  Several models are available for flush mount and surface mount installations with exposed conduit.  Available in clear, white, black and almond.  Local AHJ approval is recommended.



STI-8100

Almond, flush mount Damage Stopper with mounting hardware.

STI-8100A

Black, flush mount Damage Stopper with mounting hardware.

STI-8100-BK

White, flush mount Damage Stopper with mounting hardware.

STI-8100-W



FEATURES

  • Cover is UL Listed.
  • Cover and spacer are UL Listed for ceiling and wall applications with Sentrol detectors listed on reverse.
  • Recommended for correctional facilities with smoke detector abuse.
  • Backplate available for mounting on unstable surfaces.
  • Polycarbonate tested - 40║F (-40║C) to 120║F (49║C).
  • Smoke detector's L.E.D. remains visible.
  • Tamper resistant hardware available.
  • Lifetime warranty against breakage in normal use.
  • Appealing appearance.
  • Easy installation and easy removal for servicing.
  • Factory Mutual System approved.





DIMENSIONS AND TECHNICAL INFORMATION

For more detailed dimensions and technical information, call us at 1-800-843-6036.

Fax us at 1-336-766-3613 or email us.

MODELS AVAILABLE

STI-8100 Clear, flush mount Damage Stopper with mounting hardware.
STI-8100-A Almond, flush mount Damage stopper with mounting hardware.
STI-8100-BK Black, flush mount Damage Stopper with mounting hardware.
STI-8100-W White, flush mount Damage Stopper with mounting hardware.
STI-8130 Surface mount Damage Stopper, STI-8100,   STI-8101 conduit spacer and mounting hardware.
STI-8101 Clear, stackable two inch conduit spacer (included with STI-8130).
STI-8170 Mounting backplate for flush and surface mount models.  Recommended for irregular and unstable mounting surfaces such as drop ceilings and beams.
SUB-81 Tamper resistant screws, #8 X 2" snake eye (quantity 4) for use with STI-8100.
SUB-82 Tamper resistant screws, #8 X 1 1/2" snake eye (quantity 4) for use with STI-8130.
19038 Tamper bit for SUB-81 and SUB-82.



SMOKE DETECTOR DAMAGE STOPPER«  PRICING CHART

Model

1+

3+

STI-8100 33.60 26.88
STI-8100-A 33.60 26.88
STI-8100-B 33.60 26.88
STI-8100-W 33.60 26.88
STI-8130 41.90 33.52
STI-8101 14.20 11.36
STI-8170 27.05 21.64
SUB-81 2.83 2.26
SUB-82 2.83 2.26
19038 7.88 6.30



APPROVALS

It has been tested and listed by:
  • UL and cUL listed (No. 85Y2) for use with:  STI-8100 cover approved for ceiling or wall mount applications and either flush or surface (raceway/conduit) situations with no sensitivity change with the following smoke detectors:
  • Notifier model FSP-751
  • System Sensor model 2251
  • FCI model ASD-PL
  • Secutron model MRI-2251
  • EST model 2251F
  • Honeywell TC806B1001
  • Sentrol/GE Interlogix 611UD, 612UD, 721UD and 731UD (No sensitivity adjustment needed)
  • STI-8130 cover and spacer:
  • Sentrol/GE Interlogix models 611UD, 612UD, 612UD, 721UD and 731UD (No sensitivity adjustment needed under 300 FPM)
  • Factory Mutual System
  • California State Fire Marshal No. 7300-1416:101
  • New York City Board of Standards approved (49-00-E).
  • Local AHJ approval is recommended.

NOTE:  STI-800 series covers are to be used at your own risk if mounted over non-UL Listed product.



USE OUR SMOKE DETECTOR DAMAGE STOPPER║ with polycarbonate construction if...........
  • the risk of physical abuse to smoke detectors is severe
  • it's advisable to lessen the chances of suicide in correctional facilities and mental hospitals (slots are too small for even a pencil to be passed through them)
  • translucent unit is more aesthetically appealing
  • color selection better matches your building interior
