OUTDOOR SERVER CABINET ENCLOSURE 900 SERIES
Quest Manufacturing
 Meets
or exceeds NEMA 250 - Protection 4X and EIA 310D.Series 900 Outside Enclosure Cabinet |
 |
| Features: Designed to provide a degree of protection for enclosed equipment against falling dirt, rain, snow, sleet, windblown dust, splashing water, hose-directed water and corrosion. Includes casters for easy mobility. Features fully adjustable internal cage nut rails for #12-24 mounting screws in EIA universal spacing. Leveling feet included. Galvanized steel construction. Meets or exceeds NEMA 250 - protection 4X and EIA310D. Finished with textured polyester material--highly corrosion resistant. |
Angled Cover: Prevents corrosion and water intrusion. Hermetic Seal: Prevents water leaking into the unit, protecting the enclosed equipment. Filters: Protects equipment from potential contamination agents. Adjustable Rails: Features fully adjustable cage nut rails for #12-24 mounting equipment screws. Ventilations: Allows air flow ventilation and hot air evacuation in the enclosure. |
|
ENVIRONMENTAL CONDITIONS |
TYPE OF PROTECTION |
||||
|
3 |
3R* |
3S |
4 |
4X |
|
| Incidental contact with enclosed equipment |
x |
x |
x |
x |
x |
| Rain, snow and sleet |
x |
x |
x |
x |
x |
|
Sleet |
x |
||||
| Windblown dust and falling dirt |
x |
x |
x |
x |
|
| Hose-directed water |
x |
x |
|||
| Corrosion |
x |
||||
Web Pricing Listed Below
|
SPECIFICATIONS |
||||
|
Stock No. |
RU (Rack Units) |
Height |
Format |
Color |
|
OE9019-20-04 |
20 RU |
3' |
19" |
Gray |
|
OE9019-28-04 |
28 RU |
4' |
19" |
Gray |
|
OE9019-34-04 |
34 RU |
5' |
19" |
Gray |
|
OE9019-40-04 |
40 RU |
6' |
19" |
Gray |
|
OE9019-45-04 |
45 RU |
7' |
19" |
Gray |
|
AWG |
||||
|
Stock No. |
Structure |
Cover |
Doors |
Base |
|
OE9019-20-04 |
16 |
16 |
18 |
14 |
|
OE9019-28004 |
16 |
16 |
18 |
14 |
|
OE9019-34-04 |
16 |
16 |
18 |
14 |
|
OE9019-40-04 |
16 |
16 |
16 |
14 |
|
OE9019-45-04 |
16 |
16 |
16 |
14 |
|
EXTERNAL DIMENSIONS/PRODUCT |
||||
|
Stock No. |
A - Height |
B - Width |
C - Depth |
Load Capacity |
|
OE9019-20-04 |
3' |
27.5" |
24" |
580 lbs. |
|
OE9019-28-04 |
4' |
27.5" |
24" |
650 lbs. |
|
OE9019-34-04 |
5' |
27.5" |
24" |
700 lbs. |
|
OE9019-40-04 |
6' |
27.5" |
24" |
730 lbs. |
|
OE9019-45-04 |
7' |
27.5" |
24" |
780 lbs. |
|
EXTERNAL DIMENSIONS/PACKAGE |
||||
|
Stock No. |
Height |
Width |
Depth |
Shipping Weight |
|
OE9019-20-04 |
48" |
28" |
25" |
188 lbs. |
|
OE9019-28-04 |
62" |
28" |
25" |
250 lbs. |
|
OE9019-34-04 |
72" |
28" |
25" |
310 lbs. |
|
OE9019-40-04 |
83" |
28" |
25" |
375 lbs. |
|
OE9019-45-04 |
91" |
28" |
25" |
438 lbs. |
|
INTERNAL DIMENSIONS/PRODUCT |
||||
|
Stock No. |
A - Height |
B - Width |
C- Depth |
Load Capacity |
|
20 RU |
28" |
24" |
22.5" |
580 lbs. |
|
28 RU |
43" |
24" |
22.5" |
650 lbs. |
|
34 RU |
52" |
24" |
22.5" |
700 lbs. |
|
40 RU |
64" |
24" |
22.5" |
730 lbs. |
|
45 RU |
74" |
24" |
22.5" |
780 lbs. |
|
WEB PRICE |
||
|
ITEM # |
1-4 |
5 AND UP |
|
OE9019-20-4 |
$2,729.00 |
$2,430.00 |
|
OE9019-28-04 |
$2,879.00 |
$2,538.00 |
|
OE9019-34-04 |
$3,109.00 |
$2,799.00 |
|
OE9019-40-04 |
$3,199.00 |
$2,899.00 |
|
OE9019-45-04 |
$3,369.00 |
$2,956.00 |
