PALADIN TOOLS LAN PRONAVIGATOR™ TESTER AND REMOTE

If you're a technician on the go, you need the LAN ProNavigator™ from Paladin Tools! Two-piece tester includes main unit and remote with test results at both ends.

FEATURES:

One-button, simple testing (PASS/FAIL or fault find)
Traces wires with tone & remote lights
Quick fault analysis on coax & data cables
CAT-5, CAT-5e or CAT-6 (UTP/STP) cable testing
Detects Opens, Shorts, Crossed Wires & Split Pairs
Compact & lightweight, comfortable to hold
Test status lights at both ends (main unit & remote)

SPECIFICATIONS:

Simple PASS/FAIL test results in one second allows technicians to quickly move on to the next test site.
Generates oscillating audio tone for use with tone probes to locate tables.
Tests data and telephone cables up to 320 feet (100 metes) for proper pairing for EIA/TIA-568A, EIA/TIA-568B, Token Ring, 10 Base T, and common Category 5 configurations.
Tests unshielded UTP and shielded STP data cable.
Detects good connections, open connections, crossed wires and split pairs.
Tests common BNC connected 50 and 75 ohm coaxial cables up to 320 feet (100 meters) for continuity.
Tests coaxial cable types RG58, RG59, RG6, RG6 Quad, Belden 8281, RG8, RG11 and more.
Belt clips provided and lanyard holes embedded in case to attach to belt or wrist.
Features low battery test and auto-off function to preserve battery life.
Includes standard 9-volt dc battery.
One year warranty

TECHNICAL	MAIN	REMOTE	KIT
Weight	8 oz. (228 g)	2 oz. (57 g)	2.5 lbs. (1140 g)
Dimensions	3.45"x2.9"x1.85"	3.45"x1.6"x0.9"	8.5"x7.6"x3"
	88mm x 74mm x 47mm	87mm x 41mm x 24mm	216mm x 193mm x 76 mm

Ordering	Part Number
LAN ProNavigator™ test set (main & remote), 2 RJ45 patch cords, 2 belt clips, 12 oz. (342 g)	1543
LAN ProNavigator™ replacement remote unit with belt clip	1544
LAN ProNavigator™ test set (main & remote), 2 RJ45 patch cords, 2 BNC coaxial cables, 2 CATV "F"-to-BNC adapters, 1 BNC/BNC adapter, 1 shielded RJ45 coupler, 2 belts in durable case	901066
Adapter, CATV "F" (female) to BNC (male)	901074

PALADIN LAN PRONAVIGATOR™ PRICING CHART
Part Number	3+	1+
1543	124.99	131.24
1544	53.90	56.650
901066	184.95	194.20
901074	6.30	6.62
