POINT 5 CUSTOM IN-TRIM SERIES HI-FI IN-WALL LOUDSPEAKERS Omage In-Trim series of in-wall and in-ceiling loudspeakers make it possible to listen to music everywhere. Engineered in the United States and built with superior quality components, In-Trim is designed to deliver a high fidelity performance that is sure to satisfy everyone.
|
|
The In-Trim ITRD5/ITRD6.5/ITRD8 in-wall and in-ceiling loudspeakers are available with a 5.25" (13 cm), 6.5" (16.5 cm) and 8" (20 cm) woofer configurations. |
|
|
|
|
|
|
|
The In-Trim woofer cone is a mica filled polypropylene cone suspended with a pure rubber surround. This mica filled cone is stiffer than a polypropylene cone and is capable of a deeper bass response. The inverted dust cap establishes a strong connection between the voice coil and cone, resulting in a smoother midrange in the 4,000 to 5,000 Hz area. All these design features enhance the
In-Trim speaker series' excellent sound quality, durability and its ability
to resist tough environmental conditions such as high humidity. |
  SWIVELING
TWEETERAll Omage In-Trim in-wall loudspeakers use a 1" (25 mm) teterone synthetic silk dome tweeter for smoother highs and a flatter frequency response, so you experience the true sound of music as it was intended. This tweeter is also designed to resist a wide range of environmental conditions. A built-in protection system uses a Poly Switch (tweeter fuse) to shut down the tweeter in the event of a power overload. Swivel tweeters in both the in-wall and in-ceiling speakers are easily adjusted to create a "sweet zone" in any room configuration, enhancing the stereo imaging and sound field dramatically. |

STEREO IN CEILING SPEAKERThanks to the dual voice coil woofer and dual mylar swivel tweeters, you can be sure to hear all the music from a single impressive speaker. Performance quality is assured with a third order Linkwitz-Riley 18dB per octave crossover and our mica filled polypropylene rubber suspended cone. |
CALL US TOLL FREE: 1-800-843-6036
| PRE-CONSTRUCTION BRACKETS Available as an option for each of the In-Trim speakers is a non-static vinyl pre-construction bracket (rough-in kit). They have nailing points at 16" centers and 24" centers to meet all common building codes. With Omage's easy cutout template, pre-installation is made simple. Pre-construction brackets are available in different sizes, specific to each model.
|

|
|
Rough-in kit for In-Trim wall models |
Rough-in kit for In-Trim ceiling models
|
|
A firebox is required in most commercial in-ceiling speaker installations to prevent fire from spreading when cutting an opening in a ceiling that is rated as a fire retardant barrier. Optional fireboxes are available in three sizes for the round In-Trim models. Firebox for In-Trim ceiling models |
| COMMERCIAL IN-WALL LOUDSPEAKERS
|
|
|
|
|
|
|
| OmageŽ offers a wide variety of entry level in-wall, in-ceiling and center channel flush mount loudspeakers for background music, hi-fi music and even home theater. Use them in kitchens, dining rooms, master baths, etc., to replace regular floor-standing speakers. Grilles and front baffles of all in-wall loudspeakers can be painted to match wall color, creating an environment where great sound is heard but not seen. |
CALL US TOLL FREE: 1-800-843-6036
|
SPECIFICATIONS |
| Model | System | Woofer | Midrange | C=cone D=Dome Tweeter | Power RMS/Peak | Frequency Response | Ohms | Weight/kg/lbs | Dimension (HxWxD) mm/inches |
| IW5 | 2 way | 13cm/5" | ------ | 25mm/1"D | 50/70 | 50~20kHz | 8 | 1.2/2.6 | 240x170x70/9.4x6.6x2.7 |
| IW6.5 | 2 way | 16.5cm/6.5" | ------
|
25mm/1"D | 60/80 | 50~20kHz | 8
|
1.5/3.3 | 345x235x73/13.5x9.2x2.9 |
| IW8 | 3 way | 20cm/8" | 25mm/1"D | 25mm/1"C | 100/120 | 50~20kHz | 8
|
2.9/6.4 | 372x272x100/14.5x10.6x3.9 |
| IWC52 | 2 way | 2x13cm/5" | ------
|
25mm/1"D | 50/70 | 45~20kHz | 8
|
2.2/4.8 | 165x375x70/6.4x14.6x2.7 |
| IWC62 | 2 way | 2x16.5cm/6.5" | ------
|
25mm/1"D | 50/70 | 40~20kHz | 8
|
2.9/6.4 | 190x425x88/7.4x16.6x3.4 |
| IWRD5 | 2 way | 13cm/5 | ------
|
25mm/1"C | 50/70 | 50~20kHz | 8
|
0.8/1.8 | 190x190x70/7.4x7.4x2.7 |
| IWRD6.5 | 2 way | 16.5cm/6.5" | ------
|
25mm/1"C | 60/80 | 50~20kHz | 8
|
1.2/2.6 | 205x205x80/8.0x8.0x3.1 |
| IWRD8 | 2 way | 20cm/8" | ------
|
25mm1"C | 80/100 | 40~20kHz | 8
|
1.5/3.3 | 245x245x92/9.6x9.6x3.6 |
| IT5 | 2 way | 13.5cm/5.25" | ------
|
25mm/1"D | 70/100 | 50~20kHz | 8
|
1.4/3.0 | 254x178x74/10.0x7.0x2.9 |
| IT6.5 | 2 way | 16.5cm/6.5" | ------
|
25mm/1"D | 75/120 | 45~20kHz | 8
|
1.8/4.0 | 305x229x76/12.0x9.0x3.0 |
| IT8 | 2 way | 20cm/8" | ------
|
25mm/1"D | 90/150 | 40~20kkHz | 8
|
2.3/5.0 | 330x254x99/13.0x10.0x3.9 |
| ITRD5 | 2 way | 13.5cm/5.25" | ------
|
25mm/1"D | 70/100 | 50~20kHz | 8
|
1.1/2.5 | 203x203x74/8.0x8.0x2.9 |
| ITRD6.5 | 2 way | 16.5cm/6.5" | ------
|
25mm/1"D | 75/120 | 45~20kHz | 8
|
1.6/3.5 | 229x229x76/9.0x9.0x3.0 |
| ITRD8 | 2 way | 20cm/8" | ------
|
25mm/1"D | 90/150 | 40~20kkHz | 8
|
2.0/4.5 | 229x229x99/9.0x9.0x3.9 |
| ITRD6.5ST | 2 way | 16.5cm/6.5" | ------
|
2x13mm/0.5"C | 2x50/2x70 | 45~20kHz | 8
|
1/4/3.0 | 244x244x76/9.6x9.6x3.0 |
|
POINT 5 CUSTOM IN-WALL LOUDSPEAKERS PRICING CHART |
| Model | 1+ | 3+ |
| IW5 | $69.00/PAIR | $65.00/PAIR |
| IW6.5 | $99.00/PAIR | $95.00/PAIR |
| IW8 | $139.00/PAIR | $119.00/PAIR |
| IWC52 | $69.00/EACH | $65.00/EACH |
| IWC62 | $79.00/EACH | $69.00/EACH |
| IWRD5 | $69.00/PAIR | $59.00/PAIR |
| IWRD6.5 | $79.00/PAIR | $69.00/PAIR |
| IWRD8 | $89.00/PAIR | $79.00/PAIR |
| IT5 | $109.00/PAIR | $99.00/PAIR |
| IT6.5 | $139.00/PAIR | $119.00/PAIR |
| IT8 | $159.00/PAIR | $149.00/PAIR |
| ITRD5 | $109.00/PAIR | $99.00/PAIR |
| ITRD6.5 | $99.00/EACH | $89.00/EACH |
| ITRD6.5ST | $99.00/EACH | $89.00/EACH |
| RIK5 | $4.99/EACH | $3.99/EACH |
| RIK6.5 | $5.99/EACH | $4.99/EACH |
| RIK8 | $6.99/EACH | $5.99/EACH |
| RIKRD5 | $4.99/EACH | $3.99/EACH |
| RIKRD6.5 | $5.99/EACH | $4.99/EACH |
| RIKRD8 | $6.99/EACH | $5.99/EACH |
| FB5 | $15.00/EACH | $12.00/EACH |
| FB6.5 | $18.00/EACH | $16.00/EACH |
| FB8 | $21.00/EACH | $19.00/EACH |
CALL US TOLL FREE: 1-800-843-6036
Prices Subject to Change Without Notice.
Product Design and Specifications Subject to Change Without Notice.
Visit midsouthelectronics.com for more electronic solutions
IN-TRIM SERIES HI-FI
IN-WALL LOUDSPEAKERS
The In-Trim in-wall speakers are designed to provide a
very flat frequency response utilizing a sophisticated second order Linkwitz-Riley
crossover network. This optimizes the performance of the woofer and
tweeter integration so that there are no dips in the frequency response.
In-Trim's Linkwitz-Riley crossover has a 12dB roll-off per
octave, permitting a clean transition from woofer to tweeter, as well as a
quicker roll-off to the woofer on the low end. This prevents woofer
distortion and breakup. The crossover consists of two coils (one iron
core, one air core), two precision capacitors, one resistor and one poly
switch for tweeter protection.
The IT5/IT6.5/IT8 are also available with 5.25" (13 cm),
6.5" (16.5 cm) and 8" (20 cm) woofer configurations.
The crossover consists of two coils (one iron core, one
air core), two precision capacitors, one resistor, and one Poly switch for
tweeter protection.
WOOFER
FIREBOXES
FOR IN-TRIM ITRD SERIES
