• RCA-110 QUICKPORT CONNECTOR

• PART NUMBER -40735*t

•  * = INNER BARREL COLOR: ORANGE (O), RED (R), WHITE (W), YELLOW (Y).   t= HOUSING COLOR: IVORY (I), WHITE (W), ALMOND (A), GREY (G), BLACK (B)

• RCA CONNECTOR TRANSMITS         AUDIO/VIDEO OVER UTP

• FEATURES AND BENEFITS
• TRANSMITS AUDIO AND VIDEO SIGNALS OVER STANDARD UTP WIRING
• FLEXIBLE UTP DESIGN MAKES IT IDEAL FOR ENVIRONMENTS WITH FREQUENT ADDS, MOVES AND CHANGES, OR WHERE WIRE MEDIUM CHOICES ARE LIMITED.
• REAR 110-STYLE IDC PUNCH DOWNS FOR SIMPLE, FAST INSTALLATIONS
• GOLD-PLATED CONTACT SURFACE PROVIDES A BETTER CONNECTION
• OVERSIZED CAVITY ACCOMMODATES MALE RCA PLUGS
• FOUR COLOR-CODED MEDIA TYPES
• COMPATIBLE WITH ANY QUICKPORT WALL PLATE, HOUSING OR PANEL.
• PERFECT FOR CLASSROOM ENVIRONMENTS.

COMPONENT SPECIFICATIONS / RCA 110

• APPLICATION: LEVITON'S RCA-110 TYPE QUICKPORT CONNECTOR IS DESIGNED TO LOCALLY DISTRIBUTE BASE BAND AUDIO/VIDEO SIGNALS OVER 10-40 FEET OF UNSHIELDED TWISTED PAIR (UTP) CABLING. FEATURING STANDARD IDC SLOTS FOR QUICK AND EASY TERMINATIONS, THESE CONNECTORS ARE COMPATIBLE WITH A VARIETY OF QUICKPORT WALLPLATES AND PANELS.

• STANDARDS COMPLIANCE: MEETS ALL APPLICABLE STANDARDS: UL LISTED.

• PHYSICAL SPECIFICATIONS: SNAP-IN CONNECTOR BODIES ARE HIGH-IMPACT, FIRE RETARDANT PLASTIC RATED UL 94V-0.

• DIMENSIONS: RCA CONNECTOR: 0.636"H x .0578"W x 1.092"D

• DESIGN CONSIDERATIONS: RCA-110 QUICKPORT CONNECTORS SNAP INTO ANY HOUSING WITH THE QUICKPORT NAME, INCLUDING: FLUSH AND SURFACE MOUNT OUTLETS, MULTIMEDIA OUTLET SYSTEM, PATCH PANEL, AND PATCH BLOCKS

• USE SEPARATE CABLES FOR ANALOG AND DIGITAL SIGNALS.

• USE WITH CATEGORY 5 OR BETTER CABLING

• CHECK CLEARANCE BEHIND PROPOSED LOCATION OF MODULE, TO ENSURE SPACE FOR PROPER BEND RADIUS OF CABLING MEDIA.

• RCA CONNECTOR INSERTS ARE AVAILABLE IN ORANGE (PCM AUDIO), RED (RIGHT LINE LEVEL AUDIO), WHITE (LEFT LINE LEVEL AUDIO), AND YELLOW (COMPOSITE VIDEO). THE CONNECTOR HOUSING IS AVAILABLE IN IVORY, WHITE, ALMOND, GREY AND BLACK, TO MATCH HOUSING OR WALLPLATES.

• WARRANTY INFORMATION: ONE-YEAR LIMITED PRODUCT WARRANTY.

CLICK HERE

NEW TELEPHONE LINE DISTRIBUTION MODULE ENHANCES STRUCTURED WIRING COMPONENTS

THE NEW TELEPHONE LINE DISTRIBUTION MODULE PROVIDES EXPANDED MULTI-LOCATION PHONE, FAX, AND/OR MODEM ACCESS. ENHANCED CAPABILITIES INCLUDE:

• BRIDGE TELEPHONE SERVICE TO A MAXIMUM OF 19 CONNECTIONS IN VARIOUS COMBINATIONS OF TWO OR FOUR LINES.

• BRIDGE "LINE 1" SERVICE TO A MAXIMUM OF 12 DIFFERENT LOCATIONS.

• BRIDGE FOUR-LINE SERVICE TO A MAXIMUM OF 8 DIFFERENT LOCATIONS

• CASCADE WITH ADDED TELEPHONE LINE DISTRIBUTION MODULES TO EXPAND SYSTEM CAPACITY.

• LINK TO (CATEGORY 5e) VOICE AND DATA MODULE (S) FOR ADDED CONNECTIONS AND EASY ADDS, MOVES, AND CHANGES.

NEW TELEPHONE LINE DISTRIBUTION MODULE ENHANCES STRUCTURED WIRING COMPONENTS

• BASIC TELEPHONE  AND VIDEO UNIT CONTAINS A 1 x 9 BRIDGED TELEPHONE MODULE AND A 6-WAY VIDEO SPLITTER.

• BASIC HOME NETWORKING MODULE CONTAINS A CATEGORY 5e VOICE & DATA MODULE, A 6-WAY 2 GHz SPLITTER, AND A TELEPHONE PATCHING EXPANSION BOARD BRIDGING UP TO 4 TELEPHONE LINES TO 7 LOCATIONS VIA 8p8c CONNECTOR.

• ADVANCED HOME TELEPHONE AND VIDEO PANEL CONTAINS THE NEW TELEPHONE LINE DISTRIBUTION MODULE, A CATEGORY 5e VOICE & DATA MODULE, AND THE NEW 6-WAY 2 GHz VIDEO SPLITTER.

• 12-PORT STRUCTURED MEDIA PANEL CONTAINS THE NEW TELEPHONE LINE DISTRIBUTION MODULE, TWO CATEGORY 5e VOICE & DATA MODULES, AND A NEW 5-PORT BRACKET.

• 18-PORT STRUCTURED MEDIA PANEL CONTAINS THE NEW TELEPHONE LINE DISTRIBUTION MODULE, THREE CATEGORY 5e VOICE & DATA MODULES, AND THE NEW 5-PORT BRACKET.

• 24-PORT STRUCTURED MEDIA PANEL CONTAINS THE NEW TELEPHONE LINE DISTRIBUTION MODULE, FOUR CATEGORY 5e VOICE & DATA MODULES, AND THE NEW 5-PORT BRACKET.
