SDN Cable Cord Wire.

SDN Cable Cord Wire APPLICATIONS:
  • UL and CSA listed and OSHA acceptable. Reconized for use in Class 1 or 2. Dividion 2 hazardous locations. To be installed in trays, raceways, troughs, channels, ducts, conduit and by direct burial. Recommended for wet or dry locations and outdoors in cable trays where a sunlight resistant rating is required. Designed for control, power, lighting, telemetering, signal, relay traffic control, wherever flexible, small diameter cable is required such as cranes, hoists and some robotics applications. The cable can be used indoors and outdoors; in pendant, reeling and other flexing applications down to -55°C.
*SPECIFICATIONS: SDN Cable Cord Wire
  • Voltage: 600 Volts
  • Temperature: 90°C Dry and 75°C Wet
  • Conductors: Bare, soft annealed copper per ASTM B-3
  • Insulation: Each conductor is concentrically insulated with a 15 mil wall of high dielectric flame retardant polymer with 5 mil wall of clear polyamide (nylon) jacket extruded over primary insulation and conforming to UL requirements.

WE CAN:

Cut to your length requirements**
Ship to your Job Site
Ship from Warehouses Nation-Wide

EMAIL OR CALL US FOR PRICING AND AVAILABILITY

1-800-843-6036

Click Here to Email Us

    OnLine Order



More Industrial Cable Solutions

SDN Cable Cord Wire. Small Diameter Control Reel and Pendant SDN  UL Type TC 90°C 600 Volt Flexible And Portable Cord Cable Wire SDN Black Jacket.

SDN Cable Cord Wire in cable sizes AWG 18 16 14 12 SDN Small Diameter Control Cable 600V

WE CAN:

Cut to your length requirements**
Ship to your Job Site
Ship from Warehouses Nation-Wide

Part No VOLTAGE ITEM AWG COND *COND STRANDING (No / OD) *APPROX OD (Inches) *WGT/M'
SDN-18-2
 600 volts
SDN
 18 2 16 / .0100 0.275 46
SDN-18-3
 600 volts
SDN
 18 3 16 / .0100 0.285 50
SDN-18-4
 600 volts
SDN
 18 4 16 / .0100 0.315 60
SDN-18-5
 600 volts
SDN
 18 5 16 / .0100 0.335 71
SDN-18-6
 600 volts
SDN
 18 6 16 / .0100 0.36 83
SDN-18-7
 600 volts
SDN
 18 7 16 / .0100 0.38 106
SDN-18-8
 600 volts
SDN
 18 8 16 / .0100 0.42 109
SDN-18-9
 600 volts
SDN
 18 9 16 / .0100 0.45 120
SDN-18-10
 600 volts
SDN
 18 10 16 / .0100 0.45 126
SDN-18-11
 600 volts
SDN
 18 11 16 / .0100 0.47 135
SDN-18-12
 600 volts
SDN
 18 12 16 / .0100 0.465 142
SDN-18-13
 600 volts
SDN
 18 13 16 / .0100 0.49 153
SDN-18-14
 600 volts
SDN
 18 14 16 / .0100 0.485 165
SDN-18-15
 600 volts
SDN
 18 15 16 / .0100 0.515 170
SDN-18-16
 600 volts
SDN
 18 16 16 / .0100 0.51 175
SDN-18-17
 600 volts
SDN
 18 17 16 / .0100 0.59 230
SDN-18-18
 600 volts
SDN
 18 18 16 / .0100 0.59 230
SDN-18-19
 600 volts
SDN
 18 19 16 / .0100 0.59 240
SDN-18-21
 600 volts
SDN
 18 21 16 / .0100 0.605 270
SDN-18-24
 600 volts
SDN
 18 24 16 / .0100 0.66 285
SDN-18-25
 600 volts
SDN
 18 25 16 / .0100 0.68 300
SDN-18-30
 600 volts
SDN
 18 30 16 / .0100 0.695 335
SDN-18-37
 600 volts
SDN
 18 37 16 / .0100 0.775 386
SDN-16-2
 600 volts
SDN
 16 2 19 / .0117 0.29 51
SDN-16-3
 600 volts
SDN
 16 3 19 / .0117 0.305 62
SDN-16-4
 600 volts
SDN
 16 4 19 / .0117 0.33 77
SDN-16-5
 600 volts
SDN
 16 5 19 / .0117 0.36 92
SDN-16-6
 600 volts
SDN
 16 6 19 / .0117 0.39 107
SDN-16-7
 600 volts
SDN
 16 7 19 / .0117 0.42 123
SDN-16-8
 600 volts
SDN
 16 8 19 / .0117 0.45 137
SDN-16-9
 600 volts
SDN
 16 9 19 / .0117 0.475 165
SDN-16-10
 600 volts
SDN
 16 10 19 / .0117 0.485 165
SDN-16-11
 600 volts
SDN
 16 11 19 / .0117 0.5 180
SDN-16-12
 600 volts
SDN
 16 12 19 / .0117 0.5 188
SDN-16-13
 600 volts
SDN
 16 13 19 / .0117 0.555 225
SDN-16-14
 600 volts
SDN
 16 14 19 / .0117 0.555 240
SDN-16-15
 600 volts
SDN
 16 15 19 / .0117 0.585 255
SDN-16-16
 600 volts
SDN
 16 16 19 / .0117 0.585 258
SDN-16-17
 600 volts
SDN
 16 17 19 / .0117 0.635 290
SDN-16-18
 600 volts
SDN
 16 18 19 / .0117 0.635 290
SDN-16-19
 600 volts
SDN
 16 19 19 / .0117 0.635 296
SDN-16-21
 600 volts
SDN
 16 21 19 / .0117 0.65 340
SDN-16-24
 600 volts
SDN
 16 24 19 / .0117 0.715 367
SDN-16-25
 600 volts
SDN
 16 25 19 / .0117 0.73 380
SDN-16-30
 600 volts
SDN
 16 30 19 / .0117 0.75 432
SDN-16-37
 600 volts
SDN
 16 37 19 / .0117 0.87 556
SDN-14-2
 600 volts
SDN
 14 2 19 / .0147 0.32 78
SDN-14-3
 600 volts
SDN
 14 3 19 / .0147 0.34 84
SDN-14-4
 600 volts
SDN
 14 4 19 / .0147 0.37 104
SDN-14-5
 600 volts
SDN
 14 5 19 / .0147 0.4 127
SDN-14-6
 600 volts
SDN
 14 6 19 / .0147 0.435 147
SDN-14-7
 600 volts
SDN
 14 7 19 / .0147 0.47 165
SDN-14-8
 600 volts
SDN
 14 8 19 / .0147 0.505 200
SDN-14-9
 600 volts
SDN
 14 9 19 / .0147 0.57 235
SDN-14-10
 600 volts
SDN
 14 10 19 / .0147 0.58 246
SDN-14-11
 600 volts
SDN
 14 11 19 / .0147 0.595 270
SDN-14-12
 600 volts
SDN
 14 12 19 / .0147 0.595 290
SDN-14-13
 600 volts
SDN
 14 13 19 / .0147 0.625 305
SDN-14-14
 600 volts
SDN
 14 14 19 / .0147 0.625 325
SDN-14-15
 600 volts
SDN
 14 15 19 / .0147 0.655 340
SDN-14-16
 600 volts
SDN
 14 16 19 / .0147 0.655 354
SDN-14-17
 600 volts
SDN
 14 17 19 / .0147 0.725 400
SDN-14-18
 600 volts
SDN
 14 18 19 / .0147 0.725 410
SDN-14-19
 600 volts
SDN
 14 19 19 / .0147 0.725 430
SDN-14-21
 600 volts
SDN
 14 21 19 / .0147 0.74 470
SDN-14-24
 600 volts
SDN
 14 24 19 / .0147 0.805 510
SDN-14-25
 600 volts
SDN
 14 25 19 / .0147 0.875 520
SDN-14-30
 600 volts
SDN
 14 30 19 / .0147 0.89 660
SDN-14-37
 600 volts
SDN
 14 37 19 / .0147 0.99 785
SDN-12-2
 600 volts
SDN
 12 2 19 / .0185 0.36 109
SDN-12-3
 600 volts
SDN
 12 3 19 / .0185 0.38 115
SDN-12-4
 600 volts
SDN
 12 4 19 / .0185 0.415 146
SDN-12-5
 600 volts
SDN
 12 5 19 / .0185 0.45 177
SDN-12-6
 600 volts
SDN
 12 6 19 / .0185 0.49 209
SDN-12-7
 600 volts
SDN
 12 7 19 / .0185 0.57 230
SDN-12-8
 600 volts
SDN
 12 8 19 / .0185 0.605 294
SDN-12-9
 600 volts
SDN
 12 9 19 / .0185 0.65 325
SDN-12-10
 600 volts
SDN
 12 10 19 / .0185 0.655 350
SDN-12-11
 600 volts
SDN
 12 11 19 / .0185 0.675 375
SDN-12-12
 600 volts
SDN
 12 12 19 / .0185 0.675 395
SDN-12-13
 600 volts
SDN
 12 13 19 / .0185 0.7 430
SDN-12-14
 600 volts
SDN
 12 14 19 / .0185 0.72 455
SDN-12-15
 600 volts
SDN
 12 15 19 / .0185 0.73 480
SDN-12-16
 600 volts
SDN
 12 16 19 / .0185 0.755 505
SDN-12-17
 600 volts
SDN
 12 17 19 / .0185 0.8 530
SDN-12-18
 600 volts
SDN
 12 18 19 / .0185 0.8 555
SDN-12-19
 600 volts
SDN
 12 19 19 / .0185 0.8 605
SDN-12-21
 600 volts
SDN
 12 21 19 / .0185 0.88 680
SDN-12-24
 600 volts
SDN
 12 24 19 / .0185 0.955 773
SDN-12-25
 600 volts
SDN
 12 25 19 / .0185 0.97 782
SDN-12-30
 600 volts
SDN
 12 30 19 / .0185 1.01 1032
SDN-12-37
 600 volts
SDN
 12 37 19 / .0185 1.145 1120
